Icom F11 Programming
General Frequency coverage (Rx and Tx). IC-F11/F11S 146-174 MHz IC-F21/F21S 400-430 MHz 440-470 MHz Number of channels Total 16 (rotary type) Total 4 (toggle type) Channel spacing 12.5 KHz, 25 kHz PLL channel step 2.5 kHz, 3.125 kHz (VHF) 5KHz, 6.25KHz (UHF) Output power 5 W, 2W or 1W (VHF) 4 W, 2W or 1W (UHF) Spurious emissions 73dBc typ.
Adjacent channel power at 25KHz at 12.5KHz 70 dB typ. Frequency stability VHF UHF ±5ppm ±2.5ppm Sensitivity 0.25 µV (typ.) at 12 dB SINAD Adjacent channel selectivity at 25KHz at 12.5KHz 70dB typ. Spurious response rejection 70 dB (typ.) Audio output power 500 mW (type.) at 5% distortion an 8 ohm Current drain Receive Transmit 70 mA (standby) 250 mA (rated audio) 1.6 A (high) Dimensions (proj.
Not included) 54(W) × 128(H) × 37(D) mm Weight 310 g (with BP-209) Measurements made in accordance with EAIA-152-C/204D or TIA-603. Applicable U.S. Military Specifications Icom makes rugged products that meet MIL-STD requirements and strict environmental standards as follows. Standard MIL 810 C MIL 810 D MIL 810 E MIL 810 F Method Proc Method Proc Method Proc Method Proc Low Pressure 500.1 I 500.2 I, II 500.3 I, II 500.4 I, II High Temp. 501.1 I 501.2 I, II 501.3 I, II 501.4 I, II Low Temp. 502.1 I 502.2 I, II 502.3 I, II 502.4-3 I, II Temp. Shock 503.1 I 503.2 I 503.3 I 503.4 I Solar Radiation 505.1 I 505.2 I 505.3 I 505.4 I Rain 506.1 I, II 506.2 I, II 506.3 I, II 506.4 I, II Humidity 507.1 I, II 507.2 II, III 507.3 III 507.4 – Salt Fog 509.1 I 509.2 I 509.3 I 509.4 – Dust Blowing 510.1 I 510.2 I 510.3 I 510.4 I Vibration 514.2 VIII, X 514.3 I 514.4 I 514.5 I Shock 516.2 I, II, V 516.3 I, IV 516.4 I, V 516.5 I, V All stated specifications are subject to change without notice or obligation.
Supplied Accessories. Battery pack:BP-209. Antenna. Belt clip: MB-68.
Software to program the Icom IC-R2 scanner. Icom CS-F11 (Rev 1.2) Icom CS-F11 (Rev 1.2) (Full version, Adjust included).
Battery charger., AC adapter. Depending on version.
Two Way Radio Programming Service Radiotronics offers two way programming at our service centre. If you would prefer, we can program your radio for you.
Programming fees start at £6 (+VAT) per radio with a minimum charge of £20 (+VAT) excluding postage. If you'd like to enquire about programming, please email us on. Please do not contact us about support for self-programming radios or programming software - see below.
Software Support Unavailable Unfortunately, we cannot offer technical support for self-programming two way radios. If you choose to program your own radio, we urge that you allow plenty of time to self-learn about your radio and the programming process - it's not always straightforward. We offer a programming service at our service centre - see above.
Download Icom F11 Programming Software
Obsolete Operating Systems Tip Some programming software may require an obsolete operating system such as M.S. DOS, Windows 3.1x, Windows 95/98, or Windows XP for example. You can usually run obsolete operating systems inside virtualisation software such as virtualisation software. The obsolete operating systems can usually be legally obtained from. Software Ownership & Download Disclaimer For convenience, we offer software for download instead of physical CD delivery. Software provided by Radiotronics is supplied free of charge.
Icom F11 Programming Software
Any fee you pay to us in the process of obtaining software should be regarded as a 'download and administration fee', which simply covers the cost of data file storage and the bandwidth used when downloading the software. The 'download and administration fee' can range from £20+VAT to £99+VAT and is directly proportional to the size of the files and the quantity of files available for download. Any software Radiotronics provides will remain the property of the manufacturer and, whilst you are free to use it to configure your radio or device, you will NOT own the software.
